H02模二次諧波單腔迴旋脈塞的研究
THE STUDY OF A H02 MODE GYROMONOTRON OPERATING AT THE SECOND HARMONIC OF THE CYCLOTRON FREOUENCY
-
摘要: 設計在8mm波段的H02模二次諧波工作的單腔迴旋脈塞(gyromonotron)已獲初步結果,其峰值輸出功率約30kW。文中比較詳細地分析了二次諧波工作的物理機理,強調指出互作用的物理實質是拉莫爾半徑效應,同時討論了模式控制問題。由于在設計中從電動力學和電子學兩方面采取了模式控制措施,因此主模工作較穩定。最后還展望了二次諧波工作的迴旋脈塞的前景。
-
關鍵詞:
Abstract: Preliminary results of an 8 mm band H02 mode gyromonotron operating at the second harmonic of the cyclotron frequency are presented. The device can produce a pulse power about 30 kW. The physical mechanism of the harmonie operation is discus-sed and the mode control measures are also described. -
Н.И.Заутзев, Радиотехника и Электронника, 19(1974), 782.[2]V. Ye. Zapevalov et al., Radio Engineering and Electronic Physics, 22(1977), 86.[5]P. Sprangle and A. Drobot, IEEE Trans. on MTT, MTT-25(1977), 528.[6]陳增圭,用于Gyrotron的開放式諧振腔的設計,中國科學院電子學研究所內部報告,1980年(即將在本刊發表).[7]徐承和,緩變參量不規則波導與開放式諧振腔的理論,北京大學無線電系資料室,1981年1月.[8]E. Harris, Introduction to Modern Theoretical Physics, vol. 2, Chap. 18, p. 518. John Wiley sons, Inc. 1975. -
