電磁喇叭的相位中心研究
ON THE PHASE CENTER OF ELECTROMAGNETIC HORNS
-
摘要: 本文用解析方法研究了具有良好對稱性輻射方向圖的電磁喇叭的為常數平面的相位中心的性質。證明了,無論是對遠場還是對近場情況,=45平面的相位中心與平均相位中心都是一致的。若以單一平面相位中心來近似喇叭的相位中心,=45平面相位中心是一最佳選擇。
-
關鍵詞:
- 天線; 電磁喇叭; 相位中心
Abstract: The characteristics of the phase centers of electromagnetic horns holdingnearly symmetric pattern are presented analytically. It is proved that the phase center on the = 45 plane coincides with the average phase center, and if a single plane phase center is used to define the horn phase center approximate y, the = 45 plane phase center will be the best choice. -
M[2]W.V. T. Rush, P. D. Potter, Analysis of Reflector Antennas, Academic Press, New York, (1970), Chapter 3.[3]Y. Y. Hu, J. Franklin Inst., 271(1961), 31-36.[4]L. Shafai and A. A. Kishk, IEE Proc.-H, 132(1985)3, 207-214.[5]A. C. Ludwing, IEEE Trans. on AP, AP-21(1973)1, 116-119.[6]P. S. Kildal, IEEE Trans. on AP, AP-31(1983)1, 199-202. -
