SCN雙二次狀態變量法和優化設計
THE DESIGN OF SCN IN THE BIQUADRATIC STATE-SPACE AND ITS OPTIMIZATION
-
摘要: 本文介紹了SCN雙二次狀態變量設計法。這種方法把n個狀態的n階濾波器壓縮成用n/2個狀態來描述,從而減少了設計過程中的內存需要量。文章對電路穩定性做了詳細的討論,提出了與EL-Masry(1981)相異的穩定條件。文中考慮了電路設計中存在的參數自由度,并用它進行了網絡的優化設計。最后用設計實例驗證了作者的設計和理論。
-
關鍵詞:
- SC網絡; 狀態空間; 優化設計
Abstract: An optimal design of the switched-capactitor network (SCN) in the biquadratic state-space is developed in this paper. Only n/2 states are needed to describe n-state filters in the design, so that many storages can be saved. After discussing the stability of the circuits in detail, the stable conditions which differ from EL-Masry (1981) are given. The optimum design of networks is made by the parameter freedom which exists during the design of the circuits. And an example is given for proving the corectness of this design method. -
E. I. EL-Masry, Design on Switched-Capacitor Filters in the Biquadratic State-Space Porm, Proc. 1981 IEEE Int. Symp. on Circuits Systems, April 1981, pp. 179-182.[2]萬耀青, 梁庚榮, 陳志強, 最優化設計方法常用程序匯編, 工人出版社, 1983年, pp. 181-204. -
