橫電磁波傳輸室電場縱向不均勻性分析
ANALYSIS OF LONGITUDINAL NONUNIFORMITY OF ELECTRIC FIELD DISTRIBUTION IN TEM CELLS
-
摘要: 本文導出了橫電磁波傳輸室(TEM Cell)電場的縱向不均勻性表達式。數值結果與M.L.Crawford(1977)的實驗值吻合較好。該結果可用于校正測量探頭位置偏差帶來的測量誤差,從而提高用TEM Cell進行電磁兼容性試驗和天線探頭校準的測量精度。
-
關鍵詞:
- 傳輸線; 橫電磁波傳輸室; 電磁兼容性測量
Abstract: By utilizing transmission line theory, practical expressions for the longitudinal nonuniformity of the electric field distribution in TEM cells are obtained. Numerical results agree well with experimental ones shown by M. L. Crawford (1977) at some frequencies. The results presented can be applied in correcting errors caused by probe location deviation in the logitudinal direction so as to reach higher accuracies in EMC measurements and probe calibration with TEM cells. -
M. L. Crawford, IEEE Trans. on EMC, EMC-16(1974)4, 189-195.[2]蔡小丁,李家樾,北京郵電學院學報,11(1988)2,77.[3]Xiao-Ding Cai, Jia-Yue Li, Proc. IEE, Part H, 136(1989) 3, 191-194.[4]蔡小丁,李家樾,北京郵電學院學報,12(1989)3,17.[5]Xiao-Ding Cai, IEEE Trans. on EMC, EMC-31(1989)3, 209-217.[6]M. L. Crawford, J. L. Workman, C. Thomas, IEEE Trans. on IM, IM-26(1977)3, 225-230.[7]R. E.柯林,微波工程基礎,人民郵電出版社,1981年,第82-87頁. -
