一種新穎的具有HEMT和GaAs MMIC的Ku波段低噪聲放大器
A NOVEL Ku-BAND LOW NOISE AMPLIFIER WITH HEMT AND GaAs MMIC
-
摘要: 本文介紹了一種具有高電子遷移率晶體管(HEMT)和砷化鎵單片微波集成電路(GaAs MMIC)的Ku波段低噪聲放大器。在11.7～12.2GHz頻率范圍內,該放大器的噪聲系數小于1.9dB,相關增益大于27dB,輸入和輸出駐波比小于1.4。放大器第一級采用了HEMT和微波串聯電感反饋技術,放大器未級采用了Ku波段GsAs MMIC。設計的關鍵是采用微波串聯電感反饋方法同時獲得最佳噪聲和最小輸入駐波匹配。放大器的輸入端和輸出端均為BJ-120波導。Abstract: A novel Ku-band low noise amplifier with high electron mobility transis-ror (HEMT) and GaAs monolithic microwave integrated circuit (MMIC) has been demonstrated. Its noise figure is less than 1.9dB with an associated gain over 27dB and an input-output VSWR less than 1.4 in the frequency range of 11.7-12.2 GHz. The HEMT and the microwave series inductance feedback technique arc used in the first stage of the amplifier, and the Ku-band MMIC is used in the last stage. The key to this design is to achieve a simultaneous optimum noise match and a minimum input VSWR match by using the microwave series inductance feedback method. The BJ-120 waveguides are used in both input and output of the amplifier.
-
戴永勝等,固體電子學研究與進展,7(1987)2,150-156.[2]H. Rothe, W. Dahlke. Proc. IRE, 44(1956) 6, 811-818.[3]S. Lversen Proc. IEEE. 64(1975) 3. 540-542.[4]Sander Weinmb, IEEE Trans. on MTT, MTT-30 (1982)6. 849-853.[5]戴永勝,固體電子學研究與進展,7(1987)1,84-85.[6]戴永勝,固體電子學研究與進展,10(1990)4,406-407. -
