Boost變換器跨周期調制(PSM)的狀態空間平均模型
基金項目:
國家自然科學基金重點項目（60436030）資助課題
Space State Average Model of PSM in Boost Converter
-
摘要: 基于Boost變換器，利用狀態空間平均法對跨周調制(Pulse Skipping Modulation，PSM)進行建模和特性分析，推導出電感電流連續(CCM)和電感電流斷續(DCM)時系統變壓比，調制度M與負載的關系及系統轉換效率的理想化公式，得到PSM具有輕載下高轉換效率的結論，并設計具有PSM調制特性的控制電路，給出仿真結果。Abstract: Based on boost converter, a new mode named PSM is modeled and analyzed using space state average method. Some useful formulae such as output voltage ratio, relationship between modulation factor and load, conversion efficiency are given in this paper. The conclusion can be easily got that PSM is an available control mode with high efficiency, especially for converter with light loads. The simulation results are given by designing the control circuit with PSM characteristic.
-
Luo Ping, Luo Luyang, Li Zhaoji, Chen Guangj. Skip cycle modulation in switching DC-DC converter. IEEE 2002 International Conference on Communications, Circuits and Systems, Chengdu , China, 29 June-1 July, 2002: 1716-1719.[2]羅萍，熊富貴，李肇基, 陳光 ..開關變換器的跨周期調制模式[J].電子與信息學報.2004, 26(6):984-988瀏覽[3]Luo Ping, Li Zhaoji, Xiong Fugui, Chen Guangj. Fuzzy[4]pulse skip modulation mode in DC/DC converter. 2004 IEEE International Power Electronics Congress, CIEP'04, Celaya, Mexico, 17-22, October, 2004: 87-91.[5]Middlebrook R D, Cuk S. A general unified approach to modeling switching converter power stages, in Proc. IEEE Power Electronics Specialists Conf, 1976: 18-34.[6]張占松，蔡宣三. 開關電源的原理與設計. 北京：電子工業出版社, 2001: 303-314.[7]羅萍. 智能功率集成電路的跨周調制PSM及其測試技術研究. [博士論文], 電子科技大學, 2004.3. -
