單脈沖天線的副面散射特性
THE CHARACTERISTICS OF THE SCATTERING PATTERNS FROM A SUBREFLECTOR OF A MONOPULSE ANTENNA
-
摘要: 本文研究修正卡氏單脈沖天線的副面散射特性。首先給出計算和、差散射場的表示式,其次給出天線直徑為60左右的副面散射特性的計算結果及實測結果。本文的主要目的是通過副面散射特性的分析,說明通常單脈沖卡氏天線采用鏡面修正技術可提高天線和效率和次級差波瓣斜率。同時給出天線實測結果。
-
關鍵詞:
Abstract: This report covers the studies of the characteristics of the scattering patterns from a subreflector of the modified monopulse dual reflector antennas. In this report, at first the basic computed formulas of the far-field sum and difference scatering patterns are deduced, and then the computed and measured results of the scattering patterns for the antenna of about 60 A diameters are obtained.By the analysis and experiment of the scattering characteristics of a subreflector of the monopulse antenna, a high sum efficiency and slope of secondary difference pattern can be obtained, using optically shaped reflector approach. Finally, the measured results of the modified cassegrainian monopulse antenna are given. -
P. W. Hannan, IRE Trans. on AP, AP-9(1961),140.[2]V. Galindo, IEEE Trans. on AP, AP-12(1964), 403.[3]W .F. Williams, Microwave J., 8(1965), 79.[4]都世民,雷達技術,1979年,第3期,第56頁.[5]P. D. Potter, Electronics, 35(1962), 22.[8]W. V. T. Rusch, IEEE Trans. on AP, AP-14(1966), 266.[9]W. V. T. Rusch, Technical Report, No. 32-979, Jet Propulsion Lab., Pasadena, California,(1967), p. 31, N67-28721.[11]水沢丕雄,喜連川隆, アンテナ伝播研究會資料,A. P 67-3, P. 1.[12]喜連川隆,水沢丕雄,アンテナ伝播研究會資料,A. P 68-9, P. 1.[13]水沢丕雄,電子通信學會論文誌, 52-B, (1969), 2, 80.[14]三國良彥, アンテナ伝播研究會資料,A. P 68-9, p. 1.[18]都世民,鏡面修正天線有關問題的探肘,全國微波、天線等四個專業聯合學術年會資料,1979.[19]都世民,修正卡氏單脈沖天線的試驗報告,(內部)1980. -
