非晶硅液晶光閥的研制
RESEARCH ON LIQUID CRYSTAL LIGHT VALVE WITH AMORPHOUS SILICON
-
摘要: 用惰性小而廉價的a-Si:H膜作液晶光閥的光導層是一種理想選擇。采用阻抗匹配的方法,設計和制作了a-Si:H液晶光閥。在大屏幕投影系統上獲得了清晰的投影圖象,分辨率為201p/mm。光閥感光度測量表明,寫入光在100w,cm2以下,讀出光隨寫入光線性變化。在寫入光為100w/cm2時,瞬態響應測量結果為:上升時間60ms,下降時間80ms。
-
關鍵詞:
- 液晶光閥; 阻抗匹配; 大屏幕投影
Abstract: It is an ideal selection to use a-Si:H film, which is cheap and with small lag, as the photoconductive layer of liquid crystal light valve. By using the method of impedance matching, an a-Si:H liquid crystal light valve is designed and fabricated, and the clear image on a large screen projective system is obtained. The resolution of the valve is 201p/mm. The sensitometry measurement shows that the projection light level varies linearly with the writing light level when the latter is below 100W/cm2. The measurement of transient response at the writing light level of 100W/cm2 indicates that the rise time is 60ms and the decay time is 80ms. -
Beard T, et al. Appl. Phys. Lett. 1973,22(3): 90-92.[2]Bleha W. Laser Focus, 1993, 19(10): 111-120.[3]Efrom U,et al. J. Appl. Phys.,1985, 57(4): 1356-1368.[4]陳剛,海宇涵等,反射式非晶硅液晶光閥.液晶發現百周年紀念會議論文集,北京:1988,16-17.[5]陳剛.實時快速非晶硅液晶光閥及快速混合相變液晶研究:[碩士論文].北京:中國科學院電子學研究所,1988年.[6]海宇涵,陳剛.紅外,1989, (11):封底.[7]海宇涵,等.非晶硅液晶光閥的結構設計和初步研究:第六屆全國非晶態材料和物理學術討論會文集,佳林: 1991,113-114.[8]海宇涵,等.非晶硅液晶光閥的阻抗匹配.第六屆全國液晶會議論文集.深圳: 1991,7.[9]海宇涵,等.電子科學學刊,1988,10(6): 528-535.[10]林璇美,等.用常規PECVD方法高速沉識a-Si : H膜.第六屆全國非晶態材料和物理學術討論會文集,桂林:1991, 16-17. -
