電磁波在光柵表面上反射和衍射的理論研究
THEORETICAL STUDIES OF REFLECTION AND DIFFRACTION OF EM WAVE BY GRATING
-
摘要: 本文從嚴格的場匹配方法出發,對電磁波在矩形截面光柵上的反射和衍射進行了理論研究。對這種光柵作為頻率掃描天線的計算顯示出,不論滿足或不滿足布喇格條件,在較寬的角度范圍內入射,經調節槽寬和槽深都可獲得理想的耀射。對于不滿足布喇格條件,在兩個互易角中較大的一個入射時,-1次衍射波有較高的效率和較寬的頻帶。而對這種光柵作為奧羅管中反射鏡的特性的理論計算指出,它具有極寬的頻帶。同時本文還給出了不同頻率平面波垂直入射時的等效光柵位置,以及電磁波在光柵表面反射時所引起的相位改變。
-
關鍵詞:
- 頻率掃描天線; 光柵; -1次衍射波效率; 奧羅管; 反射功率; 等效光柵位置
Abstract: The electromagnetic field problem of a rectangular grating illuminated with TM wave is studied theoretically by means of rigorous field-matching and moment method. The numerical calculations show that the grating, as a frequency scan antenna, can produce perfect blazing in a wide range of incident angle only through adjusting the size of width and depth of the groove no matter Bragg condition is satisfied or not. Higher efficiency and broader frequency band of - 1 order diffraction wave can be achieved only at the larger reciprocal incident angle. And very broad frequency band can be expected when the grating is employed as a reflecting mirror in an orotron. The effective grating position and phase change of reflection wave by grating are also numerically presented. -
E. V. Jull, N. C. Beaulieu, An Unusual Reflection Grating Behaviour Suitable for Efficient Frequency Scanning, in 1980 IEEE Antennas Propagat., Soc. Symp. Dig., PQ, Canada, pp. 189-191.[2]A. Hessel, J. Schmoys, D. Y. Tseng, J. Opt. Soc. Am., 65(1975)4, 380-384.[3]E. V. Jull, N. C. Beaulieu, D. C. W. Hui, J. Opt. Soc. Am., A, 1(1984)2, 180-182.[4]F. S. Johansson, IEEE Trans. on AP, AP-37(1989)8, 996-1002.[5]F. S. Johansson, L. G. Josefsson, T. Lorentzon, IEEE Trans. on AP. AP-37(1989)8, 984-989.[6]V. K. Korneeukov, et al., Radiophys. Quantum Electronics, 20(1977)2, 197.[7]K. Mizuno, S. Ono, Y. Shibata, A New Electron Tube with a Perot Resonator for the Generation of Millimeter and Submillimeter Waves, Proc. of the Symp, on Submillimeter Waves, New York, N. Y., March 31, April 1, 2, (1970), pp. 115-134.[8]D. E. Wortman, et al., IEEE J. of QE, QE-17(1981)8, 1341-1348.[9]А.Ф.Александров и Друзие, Радиотехника и Электронника, 28(1983) 4, 763-766.[10]陳嘉鈕等,成都電訊工程學院學報,15(1986)3,第1-9頁.[11]郭開周,宋文森,電子科學學刊,10(1988)1,35-41.[12]宋文森,高等電磁場理論,中國科學技術大學研究生院講義,1986年.[13]楊榮生,梳齒結構(光柵)作為慢波系統和奧羅管中輻射系統時的特性的研究,中國科學院電子學研究所碩士學位論文,1989年7月. -
