大的標準TEM小室內諧振頻率的計算
THE CACLULATION OF RESONANT FREQUENCIES IN THE LARGE NBS TEM CELL
-
摘要: 本文分別用FD-TD(時域有限差分)法和不均勻劃分TLM(傳輸線矩陣)法計算標準TEM小室的諧振頻率。在FD-TD法的計算中,提出一種新的磁邊界條件的處理方法,節省了計算量,給出了大量未曾發表過的標準TEM小室內諧振頻率的計量結果。在不均勻劃分TLM方法的計算中,按小室的自然結構不均勻的劃分小室內的傳播空間,也達到了節省計算量的目的。最后,對這兩種方法和計算結果進行了比較。給出了若干結論。
-
關鍵詞:
- 橫電磁波波導; 時域數值計算; 傳輸線矩陣法
Abstract: The resonant frequencies of the NBS TEM cell have been calculated by the Finite-Difference Time-Domain (FD-TD) and irregularly graded Ttansmis-sion-Line Matrix(TLM) methods. In the calculating process by the FD-TD method a novel processing method for the magnetic wall boundary conditions is developed with which it is possible to treat only one eighth of the whole cell domain to calculate the resonant frequencies. As a result, additional useful resonant frequency data are listed. In the TLM meth ,d, the prop... -
Crawford M L. IEEE Trans. on EMC, 1974. EMC-16(4): 189-193.[2]Hill D A. J. Microwave Power. 1983, 18(6):181-195.[3]Weil C M, Gruner L. IEEE Trans. on MTT, 1984, MTT-32(1984)6, 631-648.[4]Wilson P F, Ma M T. IEEE Trans. on EMC. 1986, EMC-28 (3):125-135.[5]Yee K S. IEEE Trans. on AP, 1966, AP-14 (3): 302-307.[6]Jonhs P B, Beurle R L. Proc. IEE, 1985, 118 (9): 1203-1208.[7]Jonhs Peter B. IEEE Trans. on MTT, 1987, MTT-35 (4): 370-377.[8]Al-Mukhtar D A, Sith J E. IEE Proc.-H, 1981, 128 (6): 299-305. -
