一種應用在多孔徑寬測繪帶SAR中的CS算法
An Algorithm Based on CS Algorithm Applied in Multi-aperture Wide-Swath SAR
-
摘要: 多孔徑接收寬測繪帶SAR方法是一種較先進的高精度寬測繪帶SAR成像方法。這種方法要求先對距離向信號壓縮然后用反解矩陣求出各個測繪帶的信號，然后再進行方位向聚焦。RD算法應用在這種成像方法比較方便，但是在星載SAR成像中大多用精度較高、運算量較小的CS算法。CS算法要求先進行方位向FFT而不是距離向壓縮，所以不能直接應用在這種成像方法中。該文提出了一種基于CS算法的多孔徑成像算法，可以很方便應用于多孔徑接收寬測繪帶SAR，并進行了計算量和誤差分析，給出了仿真結果。仿真結果證實了本文所述方法的有效性。
-
關鍵詞:
- SAR;寬測繪帶;CS算法;多孔徑成像算法
Abstract: The wide-swath method based on multi-receiver is a novel and highly accuracy wide-swath method. This method needs focus in range signal at first, so RD (Range-Doppler) arithmetic can apply to the method easily while CS (Chirp Scaling) arithmetic has some difficulties. An algorithm based on CS algorithm is proposed in this paper that can be applied in the multi-aperture wide-swath SAR method. The error and operand of this algorithm is analyzed. Finally the simulation result is present, it turn out to validate the algorithm. -
Moore R K. Scanning spaceborne synthetic aperture radar with[2]integrated radiometer. IEEE Trans. on AES 1981, 17(3): 410-420.[3]Currie A, Brown M A. Wide-swath SAR. IEE Proc.-F, 1992,[4]9(2): 122-135.[5]王小青,朱敏慧. 一種寬測繪帶SAR新方法的探討[J].電子與信息學報.2003,25(10):1425-1429瀏覽[6]Goodman N A, Lin Sih Chung. Procesing of Multiple-Receiver Spaceborne Arrays for Wide-Area SAR. IEEE Trans. on GRS, 2002, 40(4): 841-852.[7]王小青，郭琨毅，盛新慶，朱敏慧. 基于距離向多孔徑接收的寬測繪帶SAR成像方法的研究[J].電子與信息學報.2004,26(5):739-745瀏覽[8]王小青. 寬測繪帶SAR方法及其仿真研究. [博士論文]中國科學院電子學研究所, 2005年1月.[9]Wang Xiaoqing, Zhu Minhui, Sheng Xinqing. The angle error estimate method in the wide swath SAR basing on multi-receiver. Journal of Electronics (China)(已錄用,待發).[10]Raney R K, Runge H, Bamler R, Cumming I G, Wong F H. Procision SAR processing using Chirp Scaling. IEEE Trans. on GRS, 1994, 32 (4): 786-799.[11]Moreira A, Mittermayer J, et al..Extended Chirp scaling algorithm for air and spaceborne SAR data processing in stripmap and scan SAR imaging modes. IEEE Trans. on GRS, 1996, 34(5): 1123-1136. -
