對速調管雙間隙輸出段間隙阻抗矩陣系數分布的分析
ANALYSIS OF THE DISTRIBUTION OF GAP INTERACTION IMPEDANCE COEFFICIENTS OF RESONANT COUPLED CAVITY OUTPUT SECTION OF BROADBAND KLYSTRONS
-
摘要: 本文用集總等效網絡的觀點對速調管雙間隙輸出段間隙阻抗系數的分布和變化規律進行了分析。文中討論了等效電路的選擇,從各部件給出的參數來推算系統的阻抗分布并從冷測到的間隙自身阻抗系數來推算轉移阻抗系數和各部件的高頻參數。
-
關鍵詞:
Abstract: In this paper, from the lumped circuit elements point of view, the distribution of gap interaction impedance coefficients of resonant coupled cavity output section of broadband klystrons is analyzed.The following topics are diseussed: 1. the seleetion of equivalent eircuit; 2. the calculation of impedance distribution with given parameters of the lumped eircuit element; 3. the calculation of transfer impedance and microwave eircuit parameters with measured self-impedances. -
M. Chodorow and J. Wessd-Berg, IRE Trans. on ED, ED-8(1961), 44.[2]H. Golde. IRE Trans. on ED, ED-8 (1961) , 192.[3]D.H. Preist and W. J. Leidigh, IEEE Trans. on ED, ED-10(1963), 201.[4]D.H. Preist and W. J. Leidigh, IEEE Trans. on ED, ED-11(1964), 369.[5]E.L.Lien, 7th International Conferenco on MOGA (1968), 115.[6]J.Gittins, Power Travelling Wave Tubes, London, The English Univ. Pr. 1964. -
