用DSP實現相參處理器I/Q通道幅相誤差自動校正
IMPLEMENTATION OF THE CORRECTOR OF ERRORS IN I Q CHANNELS WITH DSP
-
摘要: 本文介紹I/Q通道誤差自動校正的實現方法。校正網絡由組合邏輯組成,可以校正同相支路和正交支路的幅相誤差和直流偏移。校正系數由DSP根據相參測試信號算出。當幅度誤差為0.1dB,相位誤差為5時,產生的相對鏡像電平為-27dB。經過誤差自動校正后,相對鏡像電平下降到-52dB。
-
關鍵詞:
- 數字信號處理器; 相參信號處理; 誤差校正
Abstract: This paper describes the implementation of the corrector of I Q errors in coherent processor. The correcting network consists of combination logic circuit and it can correct the gain and phase imbalances and the bias errors of the in-phase and quadrature channels in coherent signal processing. The correcting coefficients are computed with DSP using a test signal. The image level without correction is about -27dB if the errors of gain and phase in the coherent processor are 0.1dB and 5 respectively. The experimental results show that the image level is reduced to -52dB from -27dB after correcting the errors. -
Sinsky A I, Wang P C P. Error analysis of a quadrature coherent detector processor. IEEE Trans on AES 1974, AES-10(11): 880-883.[2]Curchbill F E et al. The correction of I and Q errors in a coherent processor. IEEE Trans. on AES 1981, AES-17(1): 131-137. -
