螺旋耦合H○01H○02模式變換器的若干問題
SOME PROBLEMS ABOUT THE H○01H○02 MODE TRANSDUCER WITH SPIRAL COUPLING LINE
-
摘要: 本文分析了圓波導中同心螺旋線內外的圓電波H○01、H◎01之間的耦合系數,指出了文獻[1]關于H○01H○02模式變換器設計中的不妥之處。給出了較完整的設計公式。實驗證實了本文的理論分析是正確的。在3237.5 GHz頻率范圍內,變換損耗低于0.6 dB,雜模(H○01)幅度低于15 dB,輸入駐波比低于1.2。
-
關鍵詞:
Abstract: The coupling coefficient between circular-electric modes H○01 and H◎01 through a spiral line in circular waveguide is calculated. Certain corrections to S. E. Miller s design of a H○01H○02mode transducer are made. More complete design formulas are given. Agreement between experimental results and our theoretical calculations is attained. In the frequency range from 32 to 37.5 GHz, the conversion loss is less than 0.6 dB, the amplitude of unwanted mode (H○01) less than15 dB and the V. S. W. E less than 1.2. -
S. E. Miller, Wave Mode Converter, U. S. Pat. No. 3,020,459, Feb. 6. 1962.[2]S. E. Miller, BSTJ, 33(1954), 161.[3]S. E. Miller, High Frequency Power Dividing Networks, U. S. Pat. No. 2,820,202, Jan. 1958.[6]黃宏嘉,微波原理,科學出版社,1963.[7]H. G. Unger, BSTJ, 39(1960), 161.[9]王鴻昶,一種新型的H○01H○02模式變換器,微波學報(試刊),1981年,第2期,第29頁. -
