回旋管輸出窗頻率特性的研究
STUDY OF THE FREQUENCY RESPONSE OF OUTPUT WINDOW IN GYROTRON
-
摘要: 本文對回旋管輸出窗系統的傳輸特性進行了理論研究,給出了圓波導徑向突變的模式散射的近似公式,研究了輸出窗對工作模式的反射和寄生模式的散射的頻率響應。實驗證實分析是合理的。
-
關鍵詞:
Abstract: When the operating mode wave generated in a gyrotron is going through the output window section, in which the undesired scattering modes that may disturb the normal operating of gryo-tron can be excited by the discontinuities. The transmitting properties of the window section in a gyrotron are analysed theoretically. The approximate formulas for mode scattering on the radial step of cylindrical waveguides are derived. The frequency dependence of wave transmis-sions of the operating mode and undesired modes through the window system are obtained and discussed. The cold measurements show that the theoretical results are reasonable. -
R.A.Waldron著,徐鯉庭譯,被導電磁波原理,人民郵電出版社,1977,第9章,第3節.[2]Q. F. Li and K. R. Chu, Int. J. Infrared and Millimeter Waves, 13(1982), 712. -
