電網絡的回路岔集分析法
ANALYSIS OF THE ELECTRIC NETWORK BY THE BRANCH SET METHOD
-
摘要: 本文定義了描述網絡圖回路與節點關聯狀況的矩陣D,定義了回路岔集和回路岔集矩陣。提出并證明了回路節點矩陣與節點矩陣的乘積等于回路岔集矩陣的定理。定義了回路岔集導納矩陣,假設回路岔集電壓矢量作為中間計算量,導出了回路岔集方程,并提出了對電網絡的回路岔集分析法。
-
關鍵詞:
- 電網絡; 矩陣; 回路岔集; 回路節點矩陣
Abstract: The matrix D describing the relations of the loops to the nodes in the graph, the branch set based on the independent loops, and their matrix Q are defined. The theorem in which the product of the loop-node matrix D multiplied by the incidence matri A is equal to the matrix Q is put forward and proved. The admittance matrix Ytc of the branch set is defined, and it is assumed that the vector voltage of the branch set,Vle is a calculative quantity. So the equation of the branch set is derived and the branch set is derived and the branch set method is put forward. -
W. K. Chen, Applied Graph Theory, Amsterdam, North Holand, 1967, pp. 36-76.[2]陳樹柏等, 網絡圖論及其應用,科學出版社,1982年,第186-240頁.[3]v樓世博等,圖論及其應用,人民郵電出版社,1982年,第46-81頁.[4]S. Seshu, M. B. Reed, Linear Graph and Electrical Networks, Reading, Mass., 1961, ch.4.[5]成震國等,電路基本理論習題解答,人民教育出版社,1981年,第164頁. -
