Ku波段寬帶機調耿氏振蕩器
A Ku-BAND BROADBAND MECHANICAL TUNING GUNN OSCILLATOR
-
摘要: 本文介紹了Ku波段寬帶機械調諧耿氏振蕩器的實用電路結構、設計原則以及運用雙金屬補償技術得到的實驗結果。振蕩器輸出功率為50120mW;機調范圍一般為10001500MHz,最寬優于2500MHz;頻率溫度系數一般小于0.07MHz/℃,最低優于0.01MHz/℃;功率溫度系數一般小于0.015dB/℃,最低優于0.007dB/℃。Abstract: The design principles and a practical circuit of a Ku-band broadband me-chanical tuning Gunn Oscillator is described The oscillator is stabilized by bimetal compen-sation. Its power output is 50 to 120mW; the mechanical tuning bandwidth is 1000 to 1500 MHz, its maximum value is 2500MHz; the typical frequency temperature coefficient is less than 0.07MHz/℃, its minimum value is 0.01MHz/℃; and the typical power temperature coefficient is less than 0.015dB/℃, its minimum value is 0.007dB/℃.
-
G.Pfund, et al.,IEEE Trans. on MTT,MTT-22 (1974) 12,1134 -1140.[2]C.T.Rucker, et al.,IEEE Trans. on MTT,MTT-27 (1979) 12,951-957.[3]楊玉芬,固體電予學研究與進展,1989年,第3期,第326-330頁.[4]李英,電磁介質諧振器與應用,電子工業出版社,1989年,北京,第458-505,548-550頁.[5]王林田,劉鵬,介質諧振器在振蕩器方面的應用,推廣與應用微波介質諧振器學術交流會論文集, 陜西 華陽,1986年12月,中國通信學會等,第29-50頁.[6]吳正德等,3mm頻段關鍵部件的研究,全國毫米波計量測試技術發展研討會論文集,北京，I988年,中國計量測試學會,第211-225頁.[7]謝家德,電子學報,1988年,第4期,第118-119頁.[8]謝家德,微波通信,1986年,第2期,第32-41頁. -
