LSI/VLSI的任意元胞K行安置的算法
AN ALGORITHM OF K-LINE LOCATION FOR BBL IN LSI/VLSI
-
摘要: 本文提出一種適用于LSI/VLSI任意元胞布局的K行安置的算法。當矩形單元的拓樸位置確定后,每個單元有橫放、豎放兩個態共有2n個態。在K行安置時,從這2n個態中選出包絡矩形面積最小的問題,可歸結為求n個態中的包絡矩形面積最小,所以是很有效的算法。可以和結群法混合使用;在一定條件下,還可以直接用于準BBL布局。
-
關鍵詞:
- BBL布局; LSI/VLSI布圖; 計算機輔助設計
Abstract: A K-line location algorithm for buillding block cells in LSI/VLSI is presented. When the relative positions of rectangular cells are given, there are 2n states according to thetwo orientations of a cell. It is proved that to find the optimum solution from 2n states canbe reduced to calculate the n states in k-line algorithm. So the algorithm is very effectiveand can be used with association for cluster method in BBL placement. Under certain conditions, this method can also be used to pesudo BBL placement directly. -
俞明永,陸生勛,莊文君,全國第四屆集成電路CAD學術年會論文集,哈爾濱,1987年. -
